UNI63735

產品型號：UNI63735
產品說明：

價格(NTD)：$0

產品規格

Model No	UNI63735
Primary Magnification	3X
Max. Sensor Format	2/3"
FOV@Max Sensor Format, HxV(mm)	2.9 x 2.2
Working Distance (mm)	65.00
Aperture (f/#)	f/21.9
Coating	MgF2 (400-700nm)
Mount	C-Mount
Type	Telecentric Lens
Coating Specification	λ/4 MgF2 @ 550nm
Depth of Field (mm)	±0.12mm (20% @ 20 lp/mm)
FOV, 1/2\" Sensor	2.1mm
FOV, 1/3\" Sensor	1.6mm
FOV, 2/3\" Sensor	2.9mm
Filter Thread	Adapter #88-212 Required
Length excluding Threads (mm)	76.3
Maximum Diameter (mm)	18.00
Number of Elements (Groups)	5 (3)
NA, Object Side	0.068
Typical Distortion @ 588nm (%)	<0.075
Typical Telecentricity @ 588nm (°)	<0.080
Weight (g)	44
Working Distance Tolerance (mm)	±1
RoHS	Compliant
