UNI33110

產品型號：UNI33110
產品說明：

價格(NTD)：$0

產品規格

Model No	UNI33110
Primary Magnification	1X
Max. Sensor Format	2/3"
FOV@Max Sensor Format, HxV(mm)	8.8 x 6.6
Style	In-Line Illumination
Working Distance (mm)	220.00
Aperture (f/#)	f/11
Coating	MgF2 (400-700nm)
Mount	C-Mount
Type	Telecentric Lens
Coating Specification	λ/4 MgF2 @ 550nm
Compatible Light Guide/Source	1/4" (0.312") and 1/8" (0.187")
Depth of Field (mm)	±0.6mm (20% @ 20 lp/mm)
FOV, 1/2\" Sensor	6.4mm
FOV, 1/3\" Sensor	4.8mm
FOV, 2/3\" Sensor	8.8mm
Filter Thread	M34.0 x 0.5
Length excluding Threads (mm)	162.5
Maximum Diameter (mm)	36.00
Number of Elements (Groups)	5 (4)
NA, Object Side	0.044
Typical Distortion @ 588nm (%)	<0.03
Typical Telecentricity @ 588nm (°)	<0.03
Weight (g)	149
Working Distance Tolerance (mm)	±2
RoHS	Compliant
