UNI34033

UNI34033

產品型號：UNI34033
產品說明：

價格(NTD)：$0

產品規格

Model No	UNI34033
Primary Magnification	0.179X
Max. Sensor Format	35mm
FOV@Max Sensor Format, HxV(mm)	201.6 x 134.4
Aperture (f/#)	f/16
Working Distance (mm)	351
Coating	MgF2 (400-700nm)
Mount	F-Mount
Type	Telecentric Lens
Coating Specification	λ/4 MgF2 @ 520nm
Depth of Field (mm)	±25.0mm (20% @ 20 lp/mm, f/16)
FOV, 35mm Sensor	201.6mm
Number of Elements (Groups)	7 (5)
NA, Object Side	0.0056
Weight (kg)	10.04
Rear Filter Diameter (mm)	50.8
Typical Distortion @ 520nm (%)	<0.2
Typical Telecentricity @ 520nm (°)	<0.1
RoHS	Compliant
