UNI66346

產品型號：UNI66346
產品說明：

價格(NTD)：$0

產品規格

Model No	UNI66346
Coating	Vacuum Deposited Chrome, OD >3.0
Frequency (lp/mm)	240
Substrate	Float Glass
Optical Density OD	3.00
Dimensions (inches)	0.5 x 0.5
Dimensional Tolerance (inches)	±0.02
Surface Quality	60-40
Thickness (mm)	1.50
Type	Metric
Line to Line Parallelism (arcsec)	≤2
Parallelism of Pattern to Substrate (°)	±1
Surface Flatness	1λ
RoHS 2015	Compliant
REACH 201	Compliant
