BF04746-01

BF04746-01

產品型號：BF04746-01
產品說明：

價格(NTD)：$0

產品規格

Model No	BF04746-01
Fiber Type	Multimode Step-Index
Numerical Aperture	0.29
Attenuation	@ 850 nm, ≤ 12 dB/km
Water Content	Low OH
Core Diameter	200 ± 6 µm
Cladding Diameter	240 ± 5 µm
Coating Diameter	260 +5/-10 µm
Buffer Diameter	375 ± 30 µm
Core/Clad Offset	≤ 7 µm
Crimp and Cleave Compatibl	No
Coating Material	HCS®
Buffer Material	ETFE
Operating Temperature	-65 to +125℃
Short-Term Bend Radius	≥ 18 mm
Long-Term Bend Radius	≥ 30 mm
Proof Test Level	≥ 100 kpsi ( 0.689 Gpa )
