K878BN2RN-120.0W Multi-Single Emitter, 878.6nm, 120W High Power Wavelength-Stabilized Fiber Coupled Diode Laser

K878BN2RN-120.0W

產品型號：K878BN2RN-120.0W
產品說明：

價格(NTD)：$0

產品說明

Specifications（25℃）		Symbol	Unit	Minimum	Typical	Maximum
Parameter ⁽¹⁾	CW Output Power	P_o	W	115	120	-
	Threshold Current	I_th	A	-	1.2	-
	Operating Current	I_op	A	-	9	10
	Operating Voltage	V_op	V	-	35	36
	Slope Efficiency	η	W/A	-	13	-
	Electrical-to-Optical Efficiency	PE	%	-	43	-
	Center wavelength	_λc	nm	877.6	-	879.6
	Spectral width (FWHM)	δλ	nm	-	0.7	--
	Back reflection wavelength Range	λ	nm	1040	-	1200
	Back reflection isolation	-	dB	-	30	-
	Wavelength Shift with Temperature	-	nm/℃	-	0.03	-
Fiber Data	Cladding Diameter	D_clad	μm	-	220	-
	Core Diameter	D_core	μm	-	200	-
	Numeric Aperture	NA	-	-	0.22	-
	Fiber Length	L_f	m	-	2	-
	Connector	-	-	-	SMA905	-
	Minimum Bending Radius	-	mm	66	-	-
Others	ESD	V_esd	V	-	-	500
	Storage Temperature	T_stg	℃	-20	-	70
	Lead Soldering Temp	T_ls	℃	-	-	260
	Lead Soldering Time	t	sec	-	-	10
	Operating Case temperature	T_op	℃	20	-	35
	Relative Humidity	RH	%	15	-	75
Operating Notes	● Avoid eye exposure to direct or scattered radiation. ● ESD precautions must be taken. ● Please connect pins to wires by solder instead of using socket when operation current is higher than 6A. ● Soldering point should be close to the root of the pins. Soldering temperature should be lower than 260℃ and time shorter than 10 second. ● Use constant current power supply. Avoid surge current. ● Laser diode must be used according to the specifications. ● Laser diode must work with good cooling. ● Operation temperature is 20℃ 30℃. ● Storage: 20℃ +70℃ all pins short circuit.
Remark	(1) Data measured under operation output at 120W@25℃. (2) Operating temperature defined by the package case. Acceptable operating range is 20℃ - 30℃, but performance may vary. (3) Wavelength stabilized to >90% power in band of 877.1nm to 880.1nm.
