K520F03SN-0.005W Single Emitter, 520nm, 5mW Coaxial Packaged SM Diode Laser

K520F03SN-0.005W

產品型號：K520F03SN-0.005W
產品說明：

價格(NTD)：$0

產品說明

Specifications（25℃）		Symbol	Unit	Minimum	Typical	Maximum
Parameter ⁽¹⁾	CW Output Power	P_O	mW	5	-	-
	Threshold current	I_th	mA	-	50	-
	Operating current	I_op	mA	-	150	160
	Operating voltage	V_op	V	-	7.3	8
	Reverse Voltage	V_re	V	-	2	-
	Slope Efficiency	η	W/A	-	0.25	-
	Electrical-to-Optical Efficiency	PE	%	0.1	-	-
	Center wavelength ⁽²⁾	ʎ_c	nm	510	-	530
	Spectral width(FWHM)	Δ_ʎ	nm	-	-	3
	Wavelength Shift with Temperature	-	nm/℃	-	0.2	-
Fiber Data	Buffer diameter	D_buf	μm	-	250	-
	Cladding diameter	D_clad	μm	-	125	-
	Core diameter	D_core	μm	-	4	-
	Numeric aperture	NA	NA	-	0.13	-
	Fiber length ⁽³⁾	lc	m	0.9	1	1.1
	Connector	-	-	FC/FA/SC/SA/SMA905/ST
	Fiber Bend Radius		mm	-	40	-
Others	ESD	-	V	-	-	500
	Storage temperature	-	℃	-20	-	70
	Lead Soldering Temp	Tis	℃	-	-	260
	Lead Soldering Time	Tis	sec	-	-	10
	Operating case temperature	Top	℃	15	-	35
	Relative Humidity	-	%	15	-	75
Operating Notes	● Avoid eye exposure to direct or scattered radiation. ● ESD precautions must be taken. ● Please connect pins to wires by solder instead of using socket when operation current is higher than 6A. ● Soldering point should be close to the root of the pins. Soldering temperature should be lower than 260℃ and time shorter than 3 second. ● Use constant current power supply. Avoid surge current. ● Laser diode must be used according to the specifications. ● Laser diode must work with good cooling. ● A minimum bend radius should be 300 times greater than the fiber cladding diameter. ● Operation temperature is 15℃~ 35℃. ● Storage: -20℃~ +70℃, all pins short-circuit.
Remark	(1) Data measured under operation output at 5mW. (2) For other wavelength (635nm), please contact with BWT. (3) Other fibers available upon request. (4) Operating temperature defined by the package case. Acceptable operating range is 15℃~ 35℃, but performance may vary.
