Ø6mm Lenses, EFL. 10 ~ 30mm

 Ø6mm Lenses, EFL. 10 ~ 30mm

產品名稱 : Ø6mm Lenses, EFL. 10 ~ 30mm
產品說明 :

產品規格
Material N-BK7
Design Wavelength 632.8nm
Focal Length Tolerance ±1%
Diameter Tolerance +0.0/-0.1mm
Thickness Tolerance ±0.1mm
Surface Accuracy λ/4@632.8nm
Surface Quality 40-20
Centration <3 arc min
Clear Aperture >90%
Bevelling <0.2x45
AR Coating Uncoated ( AR coating is available )

產品型號 產品說明 價格(NTD) 產品數量
0 UA1116K N-BK7 Plano-Convex Lenses, Ø6mm, EFL:10mm, Uncoated $585
1 UA1470K N-BK7 Plano-Convex Lenses, Ø6mm, EFL:12mm, Uncoated $550
2 UA1222K N-BK7 Plano-Convex Lenses, Ø6mm, EFL:15mm, Uncoated $550
3 UA1700K N-BK7 Plano-Convex Lenses, Ø6mm, EFL:30mm, Uncoated $535
