Brewster Type Thin Film Polarizers
Brewster Type Thin Film Polarizers
產品名稱 : Brewster Type Thin Film Polarizers
產品說明 :
Having lasers in industrial applications creates new challenges of making the device smaller, cheaper, but robust and repeatable as well.
Polarization optics are important for both intra and extra cavity use. By having high contrast thin film polarizer in their design laser engineers can save weight and volume within their devices without influencing the output. Due to its high damage threshold and high extinction ratio Thin Film Polarizers are a good replacement for Glan laser polarizing prisms or cube polarizing beamsplitter.
產品規格
Substratel Material | UVFS |
Wavelength range | 190 – 3000 nm |
Dimensions | 5 – 200 mm |
Shape | Round, Rectangular |
Extinction ratio | 200:1 |
Transmitted wavefront distortion (P-V) | <λ/10 @ 632.8 nm (depending on size) |
Surface Quality (S-D) | 20-10 |
LIDT | High LIDT coating designs possible |
產品型號 | 產品說明 | Wavelength (nm) | Dimensions (mm) | Sharp | 價格(NTD) | 產品數量 | |
---|---|---|---|---|---|---|---|
0 | 2-BFP-0266-0254 | Brewster Type Thin Film Polarizer | 266 | Ø25.4x3 | Round | - | |
1 | 2-BFP-0266-2040 | Brewster Type Thin Film Polarizer | 266 | 20x40x5 | Rectangular | - | |
2 | 2-BFP-0343-0254 | Brewster Type Thin Film Polarizer | 343 | Ø25.4x3 | Round | - | |
3 | 2-BFP-0343-2040 | Brewster Type Thin Film Polarizer | 343 | 20x40x5 | Rectangular | - | |
4 | 2-BFP-0355-0254 | Brewster Type Thin Film Polarizer | 355 | Ø25.4x3 | Round | - | |
5 | 2-BFP-0355-2040 | Brewster Type Thin Film Polarizer | 355 | 20x40x5 | Rectangular | - | |
6 | 2-BFP-0400-0254 | Brewster Type Thin Film Polarizer | 400 | Ø25.4x3 | Round | - | |
7 | 2-BFP-0400-2040 | Brewster Type Thin Film Polarizer | 400 | 20x40x5 | Rectangular | - | |
8 | 2-BFP-0515-0254 | Brewster Type Thin Film Polarizer | 515 | Ø25.4x3 | Round | - | |
9 | 2-BFP-0515-2040 | Brewster Type Thin Film Polarizer | 515 | 20x40x5 | Rectangular | - | |
10 | 2-BFP-0532-0254 | Brewster Type Thin Film Polarizer | 532 | Ø25.4x3 | Round | - | |
11 | 2-BFP-0532-2040 | Brewster Type Thin Film Polarizer | 532 | 20x40x5 | Rectangular | - | |
12 | 2-BFP-0800-0254 | Brewster Type Thin Film Polarizer | 795-805 (centered @800) | Ø25.4x3 | Round | - | |
13 | 2-BFP-0800-2040 | Brewster Type Thin Film Polarizer | 795-805 (centered @800) | 20x40x5 | Rectangular | - | |
14 | 2-BFP-1030-0254 | Brewster Type Thin Film Polarizer | 1020-1040 (centered @1030) | Ø25.4x3 | Round | - | |
15 | 2-BFP-1030-2040 | Brewster Type Thin Film Polarizer | 1020-1040 (centered @1030) | 20x40x5 | Rectangular | - | |
16 | 2-BFP-1064-0254 | Brewster Type Thin Film Polarizer | 1064 | Ø25.4x3 | Round | - | |
17 | 2-BFP-1064-2040 | Brewster Type Thin Film Polarizer | 1064 | 20x40x5 | Rectangular | - | |
18 | 2-BFP-1550-0254 | Brewster Type Thin Film Polarizer | 1550 | Ø25.4x3 | Round | - | |
19 | 2-BFP-1550-2040 | Brewster Type Thin Film Polarizer | 1550 | 20x40x5 | Rectangular | - |
