SPF Model AOTF Controllers

產品名稱 : SPF Model AOTF Controllers
產品說明 :
The SPF AOTF Controllers are high performance, RF frequency generators. They provide fast frequency sweep (up to 16,000 λ/sec) using a direct digital synthesizer incorporated into a self-contained case with AC power supply. Standard units are provided in laboratory enclosures with one, four or up to eight RF output channels.

FEATURES
● Control of AO operation in either frequency or wavelength domain.
● Wavelength-frequency calibration by customer allowed.
● Three scan modes (stop, loop, and bounce) for both sweep and hopping.
● Control up to 4 RF output channels.
● Sweep or hopping of more than one channel at the same time.
● Minimum 8ns frequency sweep interval (8ns increment).
● Minimum 1ms frequency hopping interval.
● Standard 1000 frequency hopping steps*. Up to 65000 steps upon customer’s request*.
● Synchronization output signal during scan operation (option).
● External trigger input for frequency sweep/hopping (option).
● Customer accessible configuration file (including frequency and amplitude range control)
* For PC controlled frequency hopping.

More detail products information please contact with our services center.
