| Model No |
110-10306-0001 |
| Wavelength |
1045nm - 1080nm (Wavelength must be specified on order) |
| Clear Aperture |
25 mm |
| Peak Transmission |
>92% |
| Peak Isolation |
>30dB ; Typical >35 dB |
| Peak Rotation |
45° ± 2° |
| Damage Threshold * |
10 J/cm² at 10 ns ; 1 J/cm² at 8 ps ; 1 MW/cm² CW |
| Storage Temperature |
-10 ℃ to 60 ℃ |
| Factory Tunable Temperature |
Upon request |
| Isolated Beam Pointing ** |
Upon request |
| Input Polarization |
Horizontal / Vertical / 45° (Polarization must be specified on order) |
| Output Polarization |
Horizontal / Vertical / 45° (Polarization must be specified on order) |
| Remark * |
At customer-specified wavelength and temperature |
| Remark ** |
Input cube only |
| Note 1 |
Escape ports should be used if rejected light is >1 W or 0.15 J/cm² at 10 ns or forward light is >25 W. All stray beams should be properly terminated. |
| Note 2 |
Product specifications are subject to change. All products are RoHS compliant. |
