產品型號：09MLMS-MTF
產品說明：
產品說明：
-
Feature
• The multiple sets of classified information can be read from multi-MTF Tester.
• Automatically read the barcode of MTF Tray, according the result from MTF tester. (4 classes)
• The product can be sort and which can be picked & placed automatically.
• Distinguishing the degree from color of MTF tray.
• Using the double MTF Tray, one is classified, another one ready to replace, the production process will not be interrupted.
• If the equipment to restart, we can reserve the last coordinates.
• The material of nozzle is made of rubber and it is a standard commercial product.
• PP-Z has a Contact Edge Sensor, adjustable weight range: 20g ~ 50g.
• The method of checking lenses placed successfully ( Check Module Jam at Pocket ). Before PP-Z places a lens, it will check the value of flow sensor. After PP-Z places a lens, it will re-check the value of flow sensor in the correct state, and the contact edge sensor should not leave.
• Sorting tray stacker system will check whether the sorting tray stack tower is full. In order to avoid lenses crushing, the sorting tray stacker system will check that whether lenses protrude the sorting tray before stack the sorting tray. Sorting tray loader system will check the success of loading sorting tray.
• The user can mix different fixture/tray/nozzle according to their needs.
• The sorter contains air regulator and air tank.
• We have a guard incrustation to cover motion workspace.
• HEPA Box: Mounting on the incrustation, the HEPA supply positive pressure airflow from top to bottom. The airflow can outflow the equipment by the holes on both sides of baseplate and upside.
