UNI56321

產品型號：UNI56321
產品說明：

價格(NTD)：$0

產品規格

Model No	UNI56321
Style	Infinity Corrected
Type	Microscope Objective
Magnification	50X
NA	0.40
WD (mm)	12.0
Wavelength	266, 532nm
Wavelength Range (nm)	200 - 800
Compatible Tube Lens	Focal Length: 200mm
Depth of Focus (μm)	1.7
Horizontal FOV, 1/2&amp;quot; Sensor	0.13mm
Field of View, 18 Diameter Field Eyepiece (mm)	0.36
Horizontal FOV, 2/3&amp;quot; Sensor	0.18mm
Field of View, 24 Diameter Field Eyepiece (mm)	0.48
FL (mm)	4.00
Length excluding Threads (mm)	83.0
Manufacturer	Mitutoyo
Maximum Diameter (mm)	34.0
Resolving Power (μm)	0.7
Weight (g)	400.00
Operating Temperature (°C)	-5 to +45
RoHS 2015	Compliant
REACH 201	Compliant
Note	Example Application: passivation (insulation films) of semiconductor circuits and repair of color filters of LCD panels (defect repair)
