UNI63745

產品型號：UNI63745
產品說明：

價格(NTD)：$0

產品規格

Model No	UNI63745
Primary Magnification	1X
Max. Sensor Format	2/3"
FOV@Max Sensor Format, HxV(mm)	8.8 x 6.6
Working Distance (mm)	40.00
Aperture (f/#)	f/11
Coating	MgF2 (400-700nm)
Mount	C-Mount
Type	Telecentric Lens
Coating Specification	λ/4 MgF2 @ 550nm
Depth of Field (mm)	±0.5mm (20% @ 20 lp/mm)
FOV, 1/2\" Sensor	6.4mm
FOV, 1/3\" Sensor	4.8mm
FOV, 2/3\" Sensor	8.8mm
Filter Thread	Adapter #88-212 Required
Length excluding Threads (mm)	50.00
Maximum Diameter (mm)	18.00
Number of Elements (Groups)	5 (4)
NA, Object Side	0.045
Typical Distortion @ 588nm (%)	<0.035
Typical Telecentricity @ 588nm (°)	<0.002
Weight (g)	31
Working Distance Tolerance (mm)	±1
RoHS	Compliant
