CF05578-03

CF05578-03

產品型號：CF05578-03
產品說明：

價格(NTD)：$0

產品規格

Model No	CF05578-03
Fiber Type	Multimode Step-Index
Numerical Aperture	0.43
Attenuation	@ 850 nm, ≤ 8 dB/km
Water Content	Low OH
Core Diameter	400 ± 8 µm
HCS® Clad Diameter	430 +5 / -10 µm
ETFE Buffer Diameter	730 ± 30 µm
Core/Clad Offset	≤ 8.0 µm
Crimp and Cleave Compatibl	Yes
Coating Material	HCS
Buffer Material	ETFE
Operating Temperature	-65 to +125℃
Short-Term Bend Radius	≥ 29 mm
Long-Term Bend Radius	≥ 47 mm
Proof Test Level	≥ 100 kpsi ( 0.689 Gpa )
