BF04430-01

BF04430-01

產品型號：BF04430-01
產品說明：

價格(NTD)：$0

產品規格

Model No	BF04430-01
Fiber Type	Multimode Graded-Index
Numerical Aperture	0.2
Bandwidth	@ 1300 nm, ≥ 600 MHz-km; @ 850 nm, ≥ 600 MHz-km
Attenuation	@ 1300 nm, ≤ 0.7 dB/km; @ 850 nm, ≤ 2.4 dB/km
Core Diameter	50 ± 2.5 µm
Cladding Diameter	125 ± 1 µm
Core/Clad Offset	≤ 1 µm
Core Non-Circularity	≤ 5%
Clad Non-Circularity	≤ 1.0%
Crimp and Cleave Compatibl	No
Coating Material	Dual UV Acrylate
Operating Temperature	-40 to +85 ℃
Short-Term Bend Radius	≥ 10 mm
Long-Term Bend Radius	≥ 17 mm
Proof Test Level	100 kpsi ( 0.689 Gpa )
