產品名稱 : Ferrule Cleaner
產品說明 :
HUXCleanerTM is Pen Type In-Adaptor Ferrule Cleaner and it is no need to open the frame for ferrule cleaning inside of Adaptors. In the Fiber Optic Communication, the ferrule is used as final interconnect parts which is transfer light signal through optical fiber. The ferrule cleaning is the most important basis in the interconnects to prevent any signal error. Specially the back reflection specification which is issued more tightly at these days depend on any dust or oil, etc

Special Features
● Pen Type : First in the World (Patent under Application No.0008107)
● About 500 cleaning by 1 HUXCleaner
● No need open the Frame for ferrule cleaning inside of Adaptors
● Used advanced cleaning fiber which has better suction of water and oil than present swabs.
● Easy and Simple and Pocket Portable
● Window for showing remain cleaning fibers
● For 1.25mm (LC, MU) and 2.5mm (SC, FC, ST) ferrule type Cleaning is available
● Minimum 1/5 Cost Saving than Swab.

產品規格


Model Name HUXCleaner
No. of cleaning times by one HUXCleaner 500+
Housing Material  Plastic
Tip Material Plastic
Cleaning Fabric Special Yarn
Length (included Cap)  145mm
Packing  Individual
Refill None

How To Clean:

1. Insert HUXCleaner Tip into Adaptor and push the Ferrule.
2. Turn Rotator 1~2 clicks clockwise.

產品型號 產品說明 Connector Type 價格(NTD) 產品數量
0 PushCleaner-2.5 In-Adaptor Ferrule Cleaner For SC, FC, ST with Plastic Tip -
1 PushCleaner-1.25 In-Adaptor Ferrule Cleaner For LC, MU with Plastic Tip -
2 PushCleaner-2.5E In-Adaptor Ferrule Cleaner For SC, FC, ST, E2000 Type -
3 PushCleaner-2.0 In-Adaptor Ferrule Cleaner For 2.0mm LEMO Type -
4 PushCleaner-1.5 In-Adaptor Ferrule Cleaner For 1.5mm Military use -
5 PushCleaner-3.2 In-Adaptor Ferrule Cleaner For 3.2mm SMA Type -
