產品型號：HL-3P-INT-CAL
產品說明：
產品說明：
-
This series offers an industry-leading 3.8% uncertainty at 800 nm and a calibration over the range of 350-1100 nm with the option to select an extended calibration to 2400 nm. These sources also feature an integrated shutter controlled by either TTL pulses or manually on the front of the instrument. The internal shutter blocks light completely from the sampling device, providing the most accurate dark measurements.
Integrating Sphere Calibration Source
The HL-3P-INT-CAL model provides direct attachment and calibration with an integrating sphere with minimum port diameter of 6 mm (INT types). The INT-CAL models have a diffuser attached to the light source to be used with an integrating sphere. Simply place the INT-CAL light source at the entrance aperture of the integrating sphere.
● Stable tungsten halogen source provides consistent output for the most reliable data
● HL-3P models offer the lowest uncertainty for high confidence in your data and an integrated shutter for the most accurate dark measurements
● INT-CAL models interface directly with integrating spheres
● Digital calibration data can be loaded into Ocean Optics software for absolute intensity data
