NF03-473E-25

產品型號：NF03-473E-25
產品說明：

價格(NTD)：$0

產品規格產品說明

Model No	NF03-473E-25
Wavelength	473.0 nm
Passband Range	350.0 – 1600.0 nm
Typical 50% Notch Bandwidth	13 nm
Laser-line Blocking	OD > 6
Diameter (Mounted)	25 mm
Thickness (Mounted)	3.5 mm
Substrate Thickness (Unmounted)	2.0 mm
Substrate Type	Fused Silica
Diameter Tolerance (Mounted)	+ 0.0 / – 0.1 mm
Thickness Tolerance (Mounted)	± 0.1 mm
Clear Aperture	≥ 22 mm
Scratch-Dig	60-40
Substrate Thickness (Unmounted)	2.0 mm
Substrate Thickness Tolerance (Unmounted)	± 0.1 mm
