S1-0090

Model：S1-0090
Description：

The 1L5NT PSD functions according to the Lateral Effect Photodiode principle. It is an analogue device and therefore displays excellent position resolution. The resolution is determined by the system signal-to-noise ratio. The 1L5NT has a unique build in straylight elimination. A patented design which eliminates the decrease in speed and linearity due to straylight. The 1L5NT is operated in the biased mode.

Price(USD)：$0

Specification Content

Model No	S1-0090
PSD Type	1L5NT_CP1
Active area (mm²)	5x0.25
Leakage current (nA)	4
Noise Current pA/√Hz	0.3
Capacitance (pF)	5
Rise time (10-90%)(μs)	0.25
Package	4 pin DIL
Position non-linearity (%)	±0.1
Detector resistance (kohm)	200
Thermal drift (ppm/°C typical)	20
Bias voltage (V)	5 - 20
Maximum operating temp. (°C)	70
Maximum storage temp. (°C)	100
