Model：HPPB-2506CI-2100
Description：

Price(USD)：$0

Specification

Model No	HPPB-2506CI-2100
Material	IR Grade CaF2
Dimension D (mm)	25.4
Thickness t (mm)	6.35
Wavelength (nm)	2100
Extinction Ratio	Tp/Ts > 200:1
Surface Flatness @ 633 nm	< λ/ 10
Surface Quality	20/10
Wedge	< 3 arc min
AR Coating	R < 0.25%
Absorption	Negligible
Dimension Tolerance (mm)	< + 0.00 / – 0.20
Clear Aperture	> 85% of central diameter
