ND-150W
ND-150W
Model：ND-150W
Description：
Description：
-
ND-150W is a very simple Q-switched diode-pumped Nd:YAG laser. Pump chamber with transverse pumping, linear resonator, active Q-switching. Output energy achieves 150mJ per pulse (100-200mJ on request), pulse repetition rate is as high as 100Hz.
ND-150W is a water-cooled solution, so it requires an external chiller. Passively or forced-air cooled modification are available on special request for applications where maintenance-free is important, however their performance will be limited with 10-30Hz repetition rate.
Rigid laser head machined from the single piece of aluminium and spring-free design of mirror holders make ND-series a perfect choice for applications where the reliability is important.
ND-series lasers are equipped both with stand-alone UI (remote control with 7'' graphical display and touch panel) and RS-485 machine interface. That allows both laboratory usage and intergration into the customer's systems. By the same reasons power supply and cooling system units are performed in 19'' rack format.
Features
● Compact, but very powerful solution
● Rugged alignment-free design
● 2 years warranty
● Easy intergration with customer's system
● Fair prices
Applications
● Pumping (OPO, Ti:Sapphire, Dye laser pumping)
● Scientific (LIDAR, LIF, LIBS, LIDT)
● Material processing (laser marking, cleaning)
