Model：PICO-05
Description：
Description：
-
PICO-05 is a picosecond laser built up on an innovative optical scheme where the seed oscillator is repaced with a sole microchip crystal. The idea results in simplified layout, higher reliability and greatly reduced price. Pulse width is around 100ps, pulse repetition rate is up to 200kHz, output power achieves 5W at 1064nm and 200kHz.
PICO-05 is a forcibly cooled device. Cooling unit is a water chiller, to be purchased separately.
Power supply unit is 19’’ rack mounted (3U height) and can be driven either via RS-485 machine interface or with 7'' graphical display and touch panel.
Features
● Unbeatable cost effectiveness (based on innovative design)
● Rugged aligment-free design
● 2 years warranty
● Easy intergration with customer's system
Applications
● 2D and 3D micro-machining incl. sapphire, ceramics etc
● Hole and micro-hole drilling
● Micro-marking, marking of resistant or transparent materials
● Precise fiber cutting
