| Model No |
UNI34015 |
| Primary Magnification |
0.377X |
| Max. Sensor Format |
4/3" |
| FOV@Max Sensor Format, HxV(mm) |
47.7 x 35.8 |
| Aperture (f/#) |
f/11 - f/22 |
| Working Distance (mm) |
110 |
| Coating |
MgF2 (400-700nm) |
| Mount |
C-Mount |
| Type |
Telecentric Lens |
| Coating Specification |
λ/4 MgF2 @ 520nm |
| Depth of Field (mm) |
±4.0mm (20% @ 20 lp/mm, open) |
| FOV, 4/3\" Sensor |
45.9mm |
| FOV, 1\" Sensor |
34.0mm |
| FOV, 2/3\" Sensor |
23.3mm |
| FOV, 1/2\" Sensor |
17.0mm |
| Filter Thread |
M72 x 0.75 |
| Number of Elements (Groups) |
6 (4) |
| NA, Object Side |
0.0171 |
| Weight (kg) |
0.85 |
| Rear Filter Diameter (mm) |
25.4 |
| Typical Distortion @ 520nm (%) |
<0.05 |
| Typical Telecentricity @ 520nm (°) |
<0.1 |
| RoHS |
Compliant |
