| Model No |
UNI34028 |
| Primary Magnification |
0.179X |
| Max. Sensor Format |
APS-H |
| FOV@Max Sensor Format, HxV(mm) |
163.1 x 112.8 |
| Aperture (f/#) |
f/16 |
| Working Distance (mm) |
351 |
| Coating |
MgF2 (400-700nm) |
| Mount |
M42 x 1.0 |
| Type |
Telecentric Lens |
| Coating Specification |
λ/4 MgF2 @ 520nm |
| Depth of Field (mm) |
±26.6mm (20% @ 20 lp/mm, f/16) |
| FOV, APS-H Sensor |
163.1mm |
| Note |
Lens will cover a 39mm image circle |
| Number of Elements (Groups) |
7 (5) |
| NA, Object Side |
0.0056 |
| Rear Filter Diameter (mm) |
50.8 |
| Typical Distortion @ 520nm (%) |
<0.2 |
| Typical Telecentricity @ 520nm (°) |
<0.036 |
| RoHS |
Compliant |
