| Model No |
UNI58430 |
| Primary Magnification |
1X |
| Max. Sensor Format |
2/3" |
| FOV@Max Sensor Format, HxV(mm) |
8.8 x 6.6 |
| Working Distance (mm) |
83.00 |
| Aperture (f/#) |
f/6 - f/22 |
| Coating |
Lens Elements: BBAR from 425 - 675nm |
| Mount |
C-Mount |
| Type |
Telecentric Lens |
| Construction |
Anodized Aluminum |
| Depth of Field (mm) |
±0.5 at f/10 (20% @ 20 lp/mm) |
| FOV, 1/2\" Sensor |
6.4mm |
| FOV, 1/3\" Sensor |
4.8mm |
| Filter Thread |
M37 x 0.75 |
| Length excluding Threads (mm) |
114.00 |
| Maximum Diameter (mm) |
40.00 |
| Number of Elements (Groups) |
6 (5) |
| NA, Object Side |
0.082 |
| Resolution, Image Space MTF @ f/10 |
>40% @ 40 lp/mm |
| Typical Distortion @ 588nm (%) |
<0.060 |
| Typical Telecentricity @ 588nm (°) |
<0.045 |
| Weight (g) |
193 |
| Working Distance Tolerance (mm) |
±3 |
| RoHS |
Compliant |
